Verlegen Stahlrippen des Kessel-DIN17175 des rohr-4 Korrosionsbeständigkeit
Product Details
| Produktname: | Kohlenstoffstahl-nahtloses Rauchrohr | Anwendung: | Für Kessel des hohen, mittleren, Niederdruckes und Druckzweck |
|---|---|---|---|
| Standard: | DIN17175 | Material: | ST35.8 |
| Hervorheben |
Stahlrohr des Kessel-DIN17175,4 Rippen verlegen Kessel-Stahlrohr,DIN17175 verlegte Faden Rohr |
||
Product Description
Nahtloses Kohlenstoffstahl-Hochdruckrohr Kohlenstoffstahl-Rauchrohr-St. 37,8
Produktions-Standard: GB/T20409-2006
SteelGrade: 20G, 20MNG, 25MNG, 12CRMOG, 15CRMOG, SA210A1, SA210C, SA213T2/T12, WB36, T91, T11,
P11, P22, P92, P5, P9, R102, CR5MO, 16MO3,12CR2MOWVTIB
Faden nummerieren: 4ribs/6ribs/8ribs/12ribs
Rifled Rohr des Innengewindehochdruckkessels ist eine Art endophragm Prozesse die gewundene Linie das nahtlose Stahlrohr. Hauptanwendung herein auf Wasserkühlungswand des Kapazitätsgebrauchskessels. Normalerweise mit der Leuchtstoffröhre, die Gebrauch vergleicht, kann sie die Kernebullitionszustand unter der Betriebsbedingung der Last des hohen Fiebers beibehalten, vermeidet folglich, den filmenden Bedingung Ebullition zu senden, verhindert das Rohr, um auszubrennen, verlängert die RohrNutzungsdauer.
Chemical&Mechanical-Parameter
| Grad | C | Mangan | Si | Cr | MO | S | P |
| 20G | 0.17~0.23 | 0.35~0.65 | 0.17~0.37 | --- | --- | ≤0.020 | ≤0.025 |
| 20MnG | 0.17~0.23 | 0.70~1.00 | 0.17~0.37 | --- | --- | ≤0.020 | ≤0.025 |
| 25MnG | 0.22~0.29 | 0.70~1.00 | 0.17~0.37 | --- | --- | ≤0.020 | ≤0.025 |
| 12CrMoG | 0.08~0.15 | 0.40~0.70 | 0.17~0.37 | 0.40~0.70 | 0.40~0.55 | ≤0.020 | ≤0.025 |
| 15CrMoG | 0.12~0.18 | 0.40~0.70 | 0.17~0.37 | 0.80~1.10 | 0.40~0.55 | ≤0.020 | ≤0.025 |
| SA-210A1 | ≤0.27 | ≤0.93 | ≥0.10 | --- | --- | ≤0.035 | ≤0.035 |
| SA-210C | ≤0.35 | 0.29~1.06 | ≥0.10 | --- | --- | ≤0.035 | ≤0.035 |
| SA-213T2 | 0.10~0.20 | 0.30~0.61 | 0.10~0.30 | 0.50~0.81 | 0.44~0.65 | ≤0.025 | ≤0.025 |
| SA-213T12 | 0.05~0.15 | 0.30~0.61 | ≤0.50 | 0.80~1.25 | 0.44~0.65 | ≤0.025 | ≤0.025 |
| Grad | T (MPa) | Y (MPa) | E (%) | Härte |
| 20G | 410~550 | 245 | ≥24 | --- |
| 20MnG | ≥415 | ≥240 | ≥22 | --- |
| 25MnG | ≥485 | ≥275 | ≥20 | --- |
| 12CrMoG | 410~560 | ≥205 | ≥21 | --- |
| 15CrMoG | 440~640 | ≥235 | ≥21 | --- |
| SA-210C | ≥415 | ≥255 | ≥30 | ≤143HBW |
| SA-210A1 | ≥485 | ≥275 | ≥30 | ≤179HBW |
| SA-213T2 | ≥415 | ≥205 | ≥30 | ≤163HBW |
| SA-213T12 | ≥415 | ≥220 | ≥30 | ≤163HBW |
| Rohr-Größen für Wärmetauscher u. Kondensatore u. Kessel | |||||||||||
| Außendurchmesser | BWG | ||||||||||
| 25 | 22 | 20 | 18 | 16 | 14 | 12 | 10 | ||||
| Wandstärke Millimeter | |||||||||||
| 0,508 | 0,71 | 0,89 | 1,24 | 1,65 | 2,11 | 2,77 | 3,40 | ||||
| Millimeter | Zoll | Gewicht kg/m | |||||||||
| 6,35 | 1/4 | 0,081 | 0,109 | 0,133 | 0,174 | 0,212 | |||||
| 9,53 | 3/8 | 0,126 | 0,157 | 0,193 | 0,257 | 0,356 | 0,429 | ||||
| 12,7 | 1/2 | 0,214 | 0,263 | 0,356 | 0,457 | 0,612 | 0,754 | ||||
| 15,88 | 5/8 | 0,271 | 0,334 | 0,455 | 0,588 | 0,796 | 0,995 | ||||
| 19,05 | 3/4 | 0,327 | 0,405 | 0,553 | 0,729 | 0,895 | 1,236 | ||||
| 25,4 | 1 | 0,44 | 0,546 | 0,75 | 0,981 | 1,234 | 1,574 | 2,05 | |||
| 31,75 | 1 1/4 | 0,554 | 0,688 | 0,947 | 1,244 | 1,574 | 2,014 | 2,641 | |||
| 38,1 | 1 1/2 | 0,667 | 0,832 | 1,144 | 1,514 | 1,904 | 2,454 | 3,233 | |||
| 44,5 | 1 3/4 | 1,342 | 1,774 | 2,244 | 2,894 | 3,5 | |||||
| 50,8 | 2 | 1,549 | 2,034 | 2,574 | 3,334 | 4,03 | |||||
| 63,5 | 2 1/2 | 1,949 | 2,554 | 3,244 | 4,214 | 5,13 | |||||
| 76,2 | 3 | 2,345 | 3,084 | 3,914 | 5,094 | 6,19 | |||||
| 88,9 | 3 1/2 | 2,729 | 3,609 | 4,584 | 5,974 | 7,27 | |||||
| 101,6 | 4 | 4,134 | 5,254 | 6,854 | 8,35 | ||||||
| 114,3 | 4 1/2 | 4,654 | 5,924 | 7,734 | 9,43 | ||||||
| Form des Rohrs: Gerade u. Umkehrbogen u. gerippt u. aufgerollt | |||||||||||
| Edelstahl-Rohr: A/SA213, A/SA249, A/SA268, A/SA269, A/SA789, EN10216-5, A/SA688, B/SB163, JIS-G3463, GOST9941-81. | |||||||||||
| Kohlenstoff-&Alloy Stahlrohr: A/SA178, A/SA179, A/SA192, A/SA209, A/SA210, A/SA213, A.SA214 |
|||||||||||
