Kaltbezogenes nahtloses rostfreies helles des Rohr-TP304 getempert für Überhitzer
Product Details
| Standard: | ASTM, EN, LÄRM | Vollenden: | Getempert u. in Essig eingelegt/helles getempert |
|---|---|---|---|
| Anwendung: | boiler&heat Austauscher, Energie, Erdölchemikalie, Bergbau, Nahrung, Papier, Gas und flüssige Indust | Form: | Rundes nahtloses |
| Od: | Od: 1/8" bis 10" | Stärke: | SCH10-SCH160 |
| Hervorheben |
Überhitzer-nahtloses rostfreies Rohr,Kaltbezogenes nahtloses rostfreies Rohr TP304,Nahtloses Stahlrohr TP304 |
||
Product Description
Kaltbezogenes nahtloses rostfreies Rohr TP304, helles TP310 getempert für Überhitzer
Kaltbezogenes nahtloses rostfreies Rohr TP304, helles TP310 getempert für Überhitzer
| Einzelteil | Beschreibung | |
| Basisdaten | Materieller Grad | TP304, TP304L, TP304H, TP316, TP316L, TP316Ti, TP309S, TP310S, TP321, TP321H, TP347, TP347H, S31803, S32750, S32205 usw. |
| Außendurchmesser | 6.00mm - 48.00mm | |
| Wandstärke | 0.71mm - 2.11mm | |
| Länge | Normalerweise örtlich festgelegte Länge 6m, Dose gemäß der Anforderung des Kunden | |
| Standard | ASTM A213; ASTM A269; ASTM A312; ASTM A789; Ect ASTM A790. | |
| Prozessmethode | Kaltbezogen oder kaltgewalzt | |
ASME SA213/A213: Standardspezifikation für nahtlosen ferritischen und Austenit Legierung-Stahl-Kessel, Überhitzer und die Edelstahl-Wärmetauscher-Rohre.
ASTM A249/A249M: Standardspezifikation für geschweißten Austenit Stahlkessel, Überhitzer-Wärmetauscher und Kondensator-Rohre.
Anwendung:
1 . Für Flüssigkeits- u. Gastransport
2 . Erdölchemikalie
3 . Umweltschutz
4 . Struktur u. maschinelle Bearbeitung
5 . Strom
6 . Instrumentindustrie usw.
| Stanard-Draht-Messgerät (Kaiserdraht-Messgerät Fomerly) SWG | |||||
| SWG | Wandstärke | SWG | Wandstärke | ||
| 0 | 0,324 | 8,23 | 21 | 0,032 | 0,81 |
| 1 | 0,3 | 7,62 | 22 | 0,028 | 0,71 |
| 2 | 0,276 | 7,01 | 23 | 0,024 | 0,61 |
| 3 | 0,252 | 6,4 | 24 | 0,022 | 0,56 |
| 4 | 0,232 | 5,89 | 25 | 0,02 | 0,51 |
| 5 | 0,212 | 5,38 | 26 | 0,018 | 0,46 |
| 6 | 0,192 | 4,88 | 27 | 0,0164 | 0,42 |
| 7 | 0,176 | 4,47 | 28 | 0,0148 | 0,38 |
| 8 | 0,16 | 4,06 | 29 | 0,0136 | 0,35 |
| 9 | 0,144 | 3,66 | 30 | 0,0124 | 0,31 |
| 10 | 0,128 | 3,25 | 31 | 0,0116 | 0,29 |
| 11 | 0,116 | 2,95 | 32 | 0,0108 | 0,27 |
| 12 | 0,104 | 2,64 | 33 | 0,01 | 0,25 |
| 13 | 0,092 | 2,34 | 34 | 0,0092 | 0,23 |
| 14 | 0,08 | 2,03 | 35 | 0,0084 | 0,21 |
| 15 | 0,072 | 1,83 | 36 | 0,0076 | 0,19 |
| 16 | 0,064 | 1,63 | 37 | 0,0068 | 0,17 |
| 17 | 0,056 | 1,42 | 38 | 0,006 | 0,15 |
| 18 | 0,048 | 1,22 | 39 | 0,0052 | 0,13 |
| 19 | 0,04 | 1,02 | 40 | 0,0048 | 0,12 |
| 20 | 0,036 | 0,91 | |||
Chemische Standardzusammensetzung EN10216-5:
| Stahlsorte | C | Si | Mangan | P | S | N | Cr | Cu | MO | Notiz: | Ni | Ti | Andere | |
| maximal | maximal | maximal | ||||||||||||
| Stahlname | Stahlzahl | |||||||||||||
| X2CrNi19-11 | 1,4306 | 0,03 | ≤1 | ≤2 | 0,04 | 0,015 | ≤0.11 | 18.00 - 20,00 | - | - | - | 8.00 - 10,00 | - | - |
| X5CrNi18-10 | 1,4301 | 0,07 | ≤1 | ≤2 | 0,04 | 0,015 | ≤0.11 | 17.00 - 19,50 | - | - | - | 8.00 - 10,50 | - | - |
| X6CrNiTi18-10 | 1,4541 | 0,08 | ≤1 | ≤2 | 0,04 | 0,015 | ≤0.11 | 17.00 - 19,00 | - | - | - | 9.00 - 12,00 | 5xC bis 0,70 | - |
| X6CrNiNb18-10 | 1,4550 | 0,08 | ≤1 | ≤2 | 0,04 | 0,015 | - | 17.00 - 19,00 | - | - | 10xC bis 1,00 | 9.00 - 12,00 | - | - |
| X2CrNiMo17-12-2 | 1,4404 | 0,03 | ≤1 | ≤2 | 0,04 | 0,015 | ≤0.11 | 16.50 - 18,50 | - | 2.00 - 2,50 | - | 10.00 - 13,00 | - | - |
| X5CrNiMo17-12-2 | 1,4401 | 0,07 | ≤1 | ≤2 | 0,04 | 0,015 | ≤0.11 | 16.50 - 18,50 | - | 2.00 - 2,50 | - | 10.00 - 13,00 | - | - |
| X6CrNiMoTi17-12-2 | 1,4571 | 0,08 | ≤1 | ≤2 | 0,04 | 0,015 | - | 16.50 - 18,50 | - | 2.00 - 2,50 | - | 10.50 - 13,50 | 5xC bis 0,70 | - |
ASTM A213/A213M Standard Chemical Composition:
| Elemente | 304L (WT %) S30403 | 304 (WT %) S30400 | 316L (WT %) S31603 | 316 (WT %) S31600 |
| (c), Kohlenstoff, maximal | 0,035 | 0,08 | 0,035 | 0,08 |
| Mangan (Mangan), maximal | 2 | 2 | 2 | 2 |
| (P), Phosphor, maximal | 0,045 | 0,045 | 0,045 | 0,045 |
| (S), Schwefel, maximal | 0,03 | 0,03 | 0,03 | 0,03 |
| (Si-) Silikon, maximal | 1 | 1 | 1 | 1 |
| Nickel (Ni) | 8.0 - 12,0 | 8.0 - 11,0 | 10.0 - 14,0 | 10.0 - 14,0 |
| (Cr-) Chrom | 18.0 - 20,0 | 18.0 - 20,0 | 16.0 - 18,0 | 16.0 - 18,0 |
| Molybdän (MO) | N/A | N/A | 2.0 - 3,0 | 2.0 - 3,0 |
| Eisen (F.E.) | Bal. | Bal. | Bal. | Bal. |
| (Cu-) Kupfer | N/A | N/A | N/A | N/A |
| (N), Stickstoff | N/A | N/A | N/A | N/A |
ASTM A312/A312M Standard Chemical Composition:
| Elemente | 304L (WT %) | 316L (WT %) |
| (c), Kohlenstoff, maximal | 0,035 | 0,035 |
| Mangan (Mangan), maximal | 2 | 2 |
| (P), Phosphor, maximal | 0,045 | 0,045 |
| (S), Schwefel, maximal | 0,03 | 0,03 |
| (Si-) Silikon, maximal | 1 | 1 |
| Nickel (Ni) | 8.0 - 13,0 | 10.0 - 14,0 |
| (Cr-) Chrom | 18.0 - 20,0 | 16.0 - 18,0 |
| Molybdän (MO) | N/A | 2.0 - 3,0 |
| Eisen (F.E.) | Bal. | Bal. |
| (Cu-) Kupfer | N/A | N/A |
| (N), Stickstoff | N/A | N/A |
Product Highlights
Kaltbezogenes nahtloses rostfreies Rohr TP304, helles TP310 getempert für Überhitzer Kaltbezogenes nahtloses rostfreies Rohr TP304, helles TP310 getempert für Überhitzer Einzelteil Beschreibung Basisdaten Materieller Grad TP304, TP304L, TP304H, TP316, TP316L, TP316Ti, TP309S, TP310S, TP321, TP321H, ...
Schweißende kundengebundene Hochfrequenzkohle feuerte Dampfkessel-Teile stapeln Ekonomiser-Spule ab
High Frequency Welding Customized Coal Fired Steam Boiler Parts Stack Economizer Coil Boiler economizer Boiler Economizer is the energy improving device that helps to reduce the cost of operation by saving the fuel. The economizer in Boiler tends to make the system more energy efficient. In boilers, economizers are generally designed to exchange heat with the fluid, generally water. The exhaust from the boilers is generally in the temperature range of 200°C – 250°C, so there
Schweißendes Kessel-gewundenes Flossen-Hochfrequenzrohr für Ekonomiser-Wärmeübertragung
High Frequency Welding Boiler Spiral Fin Tube For Economizer Heat Transfer Boiler economizer Boiler Economizer is the energy improving device that helps to reduce the cost of operation by saving the fuel. The economizer in Boiler tends to make the system more energy efficient. In boilers, economizers are generally designed to exchange heat with the fluid, generally water. The exhaust from the boilers is generally in the temperature range of 200°C – 250°C, so there are a huge
Art Kessel-Teil-Rohr des Wärmetauscher-H für Gebrauchskraftwerk-Anlage
High Efficient Heat Exchang H Type High Temperature Resistance Boiler Parts For Utility/Power Station Plant Product Introduce H-fin Tubes have two steel discs,with fluorescent tubes symmetrically welded together to form fins(fins of butterfly piece)creating a shape that looks somewhat like the letter"H",creating an efficient energy saving, extension heating surface.H-fin Tubes also have a high rate of fusion welds and weld tensile strength.H-fin Tube is assembled with the H
Erweiterungs-Heizfläche-Kessel-Flossen-Rohr für Wirtschaftsmacht-Kraftwerk-Kessel
Energy Saving Extension Heating Surface Boiler Fin Tube For Industrial Power Plant Boiler Product Description H-fin Tubes have two steel discs,with fluorescent tubes symmetrically welded together to form fins(fins of butterfly piece)creating a shape that looks somewhat like the letter"H",creating an efficient energy saving, extension heating surface. H-fin Tubes also have a high rate of fusion welds and weld tensile strength.H-fin Tube is assembled with the H economizer,
