Überhitzer-Wärmetauscher-Rohr des Ekonomiser-SA210C kaltbezogen
Product Details
| Produkt-Name: | Kohlenstoffstahl-Rohr für Wärmetauscher SA210C | Anwendung: | Kessel-Rohr |
|---|---|---|---|
| Technik: | Kaltgezogen, kaltgewalzt / warmgewalzt, nahtlos | Enden-Schutz: | Lack- / Fasenenden mit Kunststoffkappen |
| Stärke: | 0.2 - 60 Millimeter | Außendurchmesser: | 13 - 1000 Millimeter |
| Hervorheben |
SA210C-Wärmetauscherrohr,SA210C-Überhitzerrohr,Rohr des Ekonomisers sa210c |
||
Product Description
Kohlenstoffstahl-Rohr für Wärmetauscher SA210C SA192 für Kessel-Rohr des mittelbarem und Kessel-Überhitzers der hohen Temperatur
Produkteinführung
ASME-Material, nahtloses Stahlrohr. Es wird hauptsächlich für Ekonomiser, Wasserwand und andere Heizflächekomponenten in den Kesseldruckteilen verwendet; das entsprechende inländische Material ist 20g/gb5310. Die Gebrauchstemperatur ist im Allgemeinen niedriger als ℃ 450.
|
Kaltbezogene Kessel-Rohre Standard u. Material |
ASTM A192/ASME SA192M ASTM A179/ASME SA179M ASTM A210/ASME SA210M: Grad: A1, C ASTM A213/ASME SA213M: Grad: T1, T2, T5, T9, T11, T12, T22, T23, T24, T91, T911, T92, T122 GB5310-2013: Grad: 20G, 25MnG, 15MoG, 15CrMoG, 20MoG, 12CrMoG, 12Cr2MoG, 12Cr1MoVG, 12Cr2MoWVTiB, 10Cr9Mo1VNb, 15CrMoG, 10CrMo910 DIN17175: ST35.8, ST45.8, 15Mo3, 13CrMo44, 10CrMo910, 14MoV63, 12Cr1MoV EN10216-1/2: Grad: P195GH, P235GH, P265GH, 13CrMo4-5, 10CrMo9-10, 16Mo3, 10CrMo5-5, X10CrMoVNb9-1 BS 3059: 320, 360, 440, 620-460, 629-590, 762 |
| Größe | O.D: 10-76mm |
| Stärke: 0.8-12mm | |
| Länge: 5.8mtr, 6mtr, mtr 12 oder gemäß Ihrer Anforderung | |
| Oberflächenbehandlung | Geölt, lackiert, malte Schwarzes |
Kaltbezogenes Rauchrohr-materielle chemische Zusammensetzung ASTM A 192
| Chemische Zusammensetzung % | |||||||
| C | Si | Mangan | P | S | Cr | Ni | Cu |
| 0.06-0.18 | ≤0.25 | 0.27-0.63 | ≤0.035 | ≤0.035 | / | / | / |
Stahl-mechanisches Eigentum ASTM A 192
| Mechanische Eigenschaften | ||
|
Streckgrenze (Mpa) |
Dehnbarer Punkt (Mpa) |
Verlängerung (%) |
| ≥180 | ≥325 | ≥35 |
Product Highlights
Kohlenstoffstahl-Rohr für Wärmetauscher SA210C SA192 für Kessel-Rohr des mittelbarem und Kessel-Überhitzers der hohen Temperatur Produkteinführung ASME-Material, nahtloses Stahlrohr. Es wird hauptsächlich für Ekonomiser, Wasserwand und andere Heizflächekomponenten in den Kesseldruckteilen verwendet; ...
