Edelstahl-nahtloses Rohr TP304 OD800mm
Product Details
| Material: | TP304, TP304L, TP304H, TP304N, TP309S, TP310S, TP310H, TP316L, TP316H, TP316Ti, TP317L, TP321H, TP34 | Fertigung: | Lösung getempert u. in Essig eingelegt |
|---|---|---|---|
| Anwendung: | Wärmetauscher, Kessel, Kondensator, Energie, gewinnend | Form: | Umkehrbogen, gerade |
| Od: | 6.00mm bis 800mm | Gewicht: | 0.5mm bis 80mm |
| Hervorheben |
Nahtloses Rohr des Edelstahl-TP304,Rohre des Edelstahls TP304,OD800mm-Edelstahl-nahtloses Rohr |
||
Product Description
Edelstahl-nahtloses Rohr, in Essig eingelegtes, festes, getempertes ASTM A269 TP304, ASME SA269 TP304L
SI TIENEN CUALQUIER REQUERIMIENTO RELATIVO en LENGUA ESPAÑOLA Nr.-ENCANTARíA APOYARLES!
Hua Dong Energy Technology hat mehr als 35 Jahre Erfahrungen für Wärmetauscherrohr/Kesselrohr,
Unsere Hauptprodukte: Rostfreie/Nickel-Legierungs-Rohr:
1>.A: Edelstahl-Grad: TP304/304L/304H, TP310S/310H, TP316/316L/316Ti/316H, TP317L/317LN, TP321/321H, TP347/347H, NO8904 (904L),
B: PH-Edelstahl: 17-4PH (1,4542), 17-7PH (1,4568), 15-7PH (1,4532)
C: Nickel-Legierungs-Stahlsorte: Hestalloy: C-276, C-4, C-22, C-2000, X, B-2, B-3, G-30, G-35. Monel: 400.401, 404, R-405, K500.
Inconel: 600, 601, 617, 625, 690, 718, 740, X-750. Incoloy: 800, 800H, 800HT, 825, 840.
Reines Nickel: Ni-200, Ni-201, Ni-270. Ns-Legierung: Ns 1101, NS1102, NS1103, NS3105.
2>. Standards: ASTM A213, A249, A269, A312, A789, A790, B163, B167, B444, B677,… und ASME, LÄRM, en, JIS, BS, GOST,…
3>. Herausdurchmesser-Größenstrecke: 0.5mm~650mm. Wandstärke: 0.05mm~60mm. Max. Länge darunter 26 meters/PC.
4>. Nahtlos u. geschweißt, Lösung, die in Essig einlegt,/getempert/poliert hell.
Vorteils-Produkte: (Kessel u. Wärmetauscher u. Kondensator-Rohr):
ASTM A213 (TP304, TP304L, TP304H, TP310S, TP316L, TP316Ti, TP317/L, TP321/H, TP347/H)
ASTM A249 (TP304, TP304L, TP316L, TP321/H)
ASTM A789 (S 31803(2205), 32750(2507), S31254 (254MO), S32304)
ASTM B163/B167/B444 für Nickel-legierter Stahl-Rohr
ASTM B677 UNS NO8904 (904L)
ASTM B111 (70400, C70600, C71500, C71640, C68700, C44300)
Anderer Standard: EN10216-5, LÄRM 17456, DIN17458, GOST9941-81, JIS-G3459, JIS-G3463
| Grad | Material Zahl |
C | Si | Mangan | P | S | N | Cr | MO | Ni | Ti | andere |
| Ferritische oder martensitische Stahle | ||||||||||||
| X2CrTi12 | 1,4512 | 0,030 |
1,00 | 1,00 | 0,040 | 0,015 | 10.50to12.50 | 6× (C+N) to0.65 | ||||
| X6CrAl13 | 1,4002 | 0,08 |
1,00 | 1,00 | 0,040 | 0,015 | 12.00to14.00 | 0.10to0.30Al | ||||
| X6Cr17 | 1,4016 | 0,08 |
1,00 | 1,00 | 0,040 | 0,015 | 16.00to18.00 | |||||
| X3CrTi17 | 1,4510 | 0,05 |
1,00 | 1,00 | 0,040 | 0,015 | 16.00to18.00 | 4× (C+N)+0.15 bis 0,80 | ||||
| X12Cr13 | 1,4006 | 0,08 bis 0,15 | 1,00 | 1,50 | 0,040 | 0,015 | 11.50to13.50 | 0,75 |
||||
| Austenitstahle | ||||||||||||
| X5CrNi18-10 | 1,4301 | 0,07 |
1,00 | 2,00 | 0,045 | 0,015 | 0,11 |
17.00to19.50 | 8.00to10.50 | |||
| X2CrNi19-11 | 1,4306 | 0,030 |
1,00 | 2,00 | 0,045 | 0,015 | 0,11 |
18.00to20.00 | 10.00to12.00 | |||
| X2CrNiN18-10 | 1,4311 | 0,030 |
1,00 | 2,00 | 0,045 | 0,015 | 0.12to0.22 | 17.00to19.50 | 8.50to11.50 | |||
| X6CrNiTi18-10 | 1,4541 | 0,08 |
1,00 | 2,00 | 0,045 | 0,015 | 17.00to19.00 | 9.00to12.00 | 5×C bis 0,70 | |||
| X6CrNiNb18-10 | 1,4550 | 0,08 |
1,00 | 2,00 | 0,045 | 0,015 | 17.00to19.00 | 9.00to12.00 | 10×Cto1.00Nb | |||
| X5CrNiMo17-12-2 | 1,4401 | 0,07 |
1,00 | 2,00 | 0,045 | 0,015 | 0,11 |
16.50to18.50 | 2.00to2.50 | 10.00to13.00 | ||
| X2CrNiMo17-12-2 | 1,4404 | 0,030 |
1,00 | 2,00 | 0,045 | 0,015 | 0,11 |
16.50to18.50 | 2.00to2.50 | 10.00to13.00 | ||
| X6CrNiMoTi17-12-2 | 1,4571 | 0,08 |
1,00 | 2,00 | 0,045 | 0,015 | 16.50to18.50 | 2.00to2.50 | 10.50to13.50 | 5×C bis 0,70 | ||
| X2CrNiMoN17-13-3 | 1,4429 | 0,030 |
1,00 | 2,00 | 0,045 | 0,015 | 0.12to0.22 | 16.50to18.50 | 2.50to3.00 | 11.00to14.00 | ||
| X2CrNiMo18-14-3 | 1,4435 | 0,030 |
1,00 | 2,00 | 0,045 | 0,015 | 0,11 |
17.00to19.00 | 2.50to3.00 | 12.50to15.00 | ||
| X3CrNiMo17-13-3 | 1,4436 | 0,05 |
1,00 | 2,00 | 0,045 | 0,015 | 0,11 |
16.50to18.50 | 2.50to3.00 | 10.50to13.00 | ||
| X2CrNiMoN17-13-5 | 1,4439 | 0,030 |
1,00 | 2,00 | 0,045 | 0,015 | 0.12to0.22 | 16.50to18.50 | 4.00to5.00 | 12.50to14.50 | ||
Spezifikation:
ASME SA213/A213: Standardspezifikation für nahtlose ferritische und Austenitlegierung
Stahlkessel-, Überhitzer-und Edelstahl-Wärmetauscher-Rohre.
ASTM A249/A249M: Standardspezifikation für geschweißten Austenit Stahlkessel, SuperheaterHeat-Austauscher und Kondensator-Rohre.
Materieller Grad:
| Amerikanischer Standard |
Austenitstahl: TP304, TP304L, TP304H, TP304N, TP310S, TP316, TP316L, TP316Ti, TP316H, TP317, TP317L, TP321, TP321H, TP347, TP347H, 904L… Andere: TP405, TP409, TP410, TP430, TP439,… |
| Europen-Standard | 1,4301, 1,4307, 1,4948, 1,4541, 1,4878, 1,4550, 1,4401, 1,4404, 1,4571, 1,4438, 1,4841, 1,4845, 1,4539, 1,4162, 1,4462, 1,4362, 1,4410, 1,4501 |
| Russland-Standard | 08Х17Т, 08Х13,12Х13,12Х17,15Х25Т, 04Х18Н10,08Х20Н14С2, 08Х18Н12Б, 10Х17Н13М2Т, 10Х23Н18,08Х18Н10,08Х18Н10Т, 08Х18Н12Т, 08Х17Н15М3Т, 12Х18Н10Т, 12Х18Н12Т, 12Х18Н9, 17Х18Н9, 08Х22Н6Т, 06ХН28МДТ |
Größen-Strecke:
| Produktion | Außendurchmesser | Wandstärke |
| Wärmetauscher-Rohr | 6.00mm bis 600mm | 0.5mm bis 50mm |
Abschließendes Vollenden
Die Lösung temperte u. legte in Essig ein,/helles getempert.
Art von Rohren:
Spule, Umkehrbogen u. gerades.
Product Highlights
