Warm gewalzte Stahlplatte SAE 1045 4 - 120mm CK 45 für allgemeine Maschinerie-Teile
Product Details
| Oberfläche: | Warm gewalzte Kohlenstoffstahl-Platte | Material: | SAE 1045 |
|---|---|---|---|
| Stärke: | 5mm-600mm | Breite: | 200mm-2500mm |
| Bündelgewicht: | 3MT-6MT | Länge: | 100mm bis 12000mm |
| Hervorheben |
Platte astm a36,kaltgewalzte Platte |
||
Product Description
Warm gewalztes SAE 1045 4-120mm CK 45 carben Stahlplatte für allgemeine Maschinerieteile, Bergbau, Raffinerie
Größen
Stärke: 5-600mm
Breite: 200-2500mm
Länge: 1 00-12000mm
Anwendung
- Kohlenstoffstahl AISI 1045 benutzt für die Herstellung des Würfelbrettes, allgemeine Maschinerieteile.
- Bestandteile für Fahrzeuge, Wellen, Buchsen, Kurbelwellen, Verbindungsstangen und Teile für das Maschinenbauwesen und -stahl für Äxte, Messer, hämmert etc.
Gleichwertiger Grad
| GB | LÄRM | N-Düngung | SS | JIS | BS | AISI | ISO |
| 45# | 1,0503 | C45 | 1650 | S45C | IC45/080A47 | 1045 | C45E4 |
Chemische Analyse
| NEIN. | C | Mangan | Si | Cr | Cu | Ni | P | S | ||||||||
| Aisi 1045 | 0.43~0.50 | 0.6~0.9 | 0.10~0.60 | ≤0.40 | ≤ 0,50 | |||||||||||
| DIN1.0503 | 0.42~0.48 | 0.6~0.9 | 0.15~0.35 | ≤0.15 | ≤0.3 | ≤0.2 | ||||||||||
| JIS S45C | 0.42~0.50 | 0.5~0.8 | ≤0.40 | ≤0.40 | ≤ 0,4 | |||||||||||
| GB45 | 0.42~0.50 | 0.5~0.8 | 0.17~0.37 | ≤0.25 | ≤0.25 | ≤0.3 | ≤0.035 | ≤0.035 | ||||||||
Mechanische Eigenschaften
| Vergütung | Schmieden | Mildern und Verhärtung | Normalisierung | |||||||||||||
|
Unterkritisches Ausglühen: 650~700 Isothermalausglühen: 820~860 |
1100~850 |
Mildern: 550~660 Verhärtung: Wasser 820~860 |
840~880 | |||||||||||||
Wärmebehandlung
Weichglühen: Hitze zu 550-650°C, kühlen langsam ab.
Härte nach der Vergütung: Maximum 269HB
Verhärtung: °C 820 - 870
Normalisierung von Temperatur: 840-870°C
Product Highlights
Warm gewalztes SAE 1045 4-120mm CK 45 carben Stahlplatte für allgemeine Maschinerieteile, Bergbau, Raffinerie Größen Stärke: 5-600mm Breite: 200-2500mm Länge: 1 00-12000mm Anwendung - Kohlenstoffstahl AISI 1045 benutzt für die Herstellung des Würfelbrettes, allgemeine Maschinerieteile. - Bestandteil...
