Industrie-Kessel-Stahlrohr für Wärmetauscher-Kondensator-kaltbezogenes kohlenstoffarmes
Product Details
| Standard: | API/CE/ISO /TUV | Produkt-Name: | Kohlenstoffstahl-Rohr-Rauchrohr für Wärmetauscher |
|---|---|---|---|
| Anwendung: | Industriekessel | Oberflächenbehandlung: | Trocknen Sie den beschichteten Lack |
| Hervorheben |
Kaltbezogene Wasserwandrohre,Kaltbezogenes kohlenstoffarmes U-Rohr |
||
Product Description
Kaltbezogenes kohlenstoffarmes nahtloses StahlRauchrohr für Wärmeaustauscher-und Kondensator-Rohre
Kaltbezogenes kohlenstoffarmes nahtloses Stahlrohr ASTM A179/(ASME SA179) für Wärmeaustauscher-und Kondensator-Rohre
ASTM A179/(ASME SA179)
| Nahtloser kaltbezogener kohlenstoffarmer Stahlwärmetauscher und Conderser-Rohre | |
| Anwendung | Für Röhrenwärmeaustauscher, Kondensatore und ähnlichen Wärmeübertragungsapparat. |
| Größe (Millimeter) | O.D.: 6.0~114.0 W.T.: 1~15 L: maximale 12000 |
Grad und chemische Zusammensetzung (%)
| Chemische Zusammensetzung | C | Mangan | P≤ | S≤ | Si≤ |
| 0.06-0.18 | 0.27-0.63 | 0,035 | 0,035 | 0,25 |
Die Toleranz auf O.D. und W.T. (SA-450/SA-450M)
| Od in (Millimeter) | + | - | GEWICHT in (Millimeter) | + | - |
| <1> | 0,10 | 0,10 | ≤1.1/2 (38,1) | 20% | 0 |
| 1~1.1/2 (25.4~38.1) | 0,15 | 0,15 | >1.1/2 (38,1) | 22% | 0 |
| >1.1/2~<2> | 0,20 | 0,20 | |||
| 2~<2> | 0,25 | 0,25 | |||
| 2.1/2~<3> | 0,30 | 0,30 | |||
| 3~4 (76.2~101.6) | 0,38 | 0,38 | |||
| >4~7.1/2 (101.6~190.5) | 0,38 | 0,64 | |||
| >7.1/2~9 (190.5~228.6) | 0,38 | 1,14 |
Product Highlights
Kaltbezogenes kohlenstoffarmes nahtloses StahlRauchrohr für Wärmeaustauscher-und Kondensator-Rohre Kaltbezogenes kohlenstoffarmes nahtloses Stahlrohr ASTM A179/(ASME SA179) für Wärmeaustauscher-und Kondensator-Rohre STAHL PIPE/TUBE ASTM A179/(ASME SA179) der inländischen Produkte kaltbezogenes ...
