Wärmetauscher-Kessel-Stahlrohr Standard-DIN2391 ST37.4 NBK 12*1MM
Product Details
| Produkt-Name: | Kohlenstoffstahl-Rauchrohr-Wärmetauscher-nahtloses Rohr | Anwendung: | Kessel-Wärmetauscher |
|---|---|---|---|
| Standard: | DIN2391 | Material: | ST37.4, ST52.4 |
| Hervorheben |
Stahlrohr DIN2391 ST37.4 NBK,Wärmetauscher-Rohr DIN2391 ST37.4,Kessel-Stahlrohr ST37.4 NBK |
||
Product Description
Kohlenstoffstahl-Rauchrohr-Wärmetauscher-nahtloses Rohr DIN2391 ST37.4 NBK 12*1MM
Kohlenstoffstahl-Rauchrohr-Wärmetauscher-nahtloses Rohr DIN2391 ST37.4 NBK 12*1MM
Kaltbezogene nahtlose Rohre der Präzisions-DIN2391 und Rohre, GR St35 St45 St52 St37.4, kalter fertiger Gebrauch des nahtlosen Rohres für hydraulisches und pneumatisches.
Lieferungs-Status: NBK (+N) BKW (+LC) GBK (+A) BKS (+SR) BK (+C) GEWICHT Ods x = 4~120 x 0.5~15mm
DIN2391 St52.4+N phosphatierte hydraulisches Rohr
Atmosphäre.
| Stahlsorte |
Chemische Zusammensetzung,
als Prozentsatz durch Masse
|
|||||
| Symbol |
Material
Zahl
|
C-Maximum. | Simaximum. | Mangan |
P
Maximum.
|
S
Maximum.
|
| Si St. 30 | 1,0211 | 0,10 | 0,30 | <> | 0,025 | 0,025 |
| Al St. 30 | 1,0212 | 0,10 | 0,05 | <> | 0,025 | 0,025 |
| St. 35 | 1,0308 | 0,17 | 0,35 | <> | 0,025 | 0,025 |
| St. 45 | 1,0408 | 0,21 | 0,35 | <> | 0,025 | 0,025 |
| St. 52 | 1,0580 | 0,22 | 0,55 | <> | 0,025 | 0,025 |
|
Die folgenden Legierungselemente werden addiert möglicherweise:
Notiz:: <>
|
||||||
| Stahlsorte | Chemische Zusammensetzung (%): | ||||||
| Stahlname | Stahlzahl | C maximal | Si maximal | Mangan | P maximal | S maximal | Alminute |
| E215 | 1,0212 | 0,10 | 0,05 | 0,70 | 0,025 | 0,025 | 0,025 |
| E235 | 1,0308 | 0,17 | 0,35 | 1,20 | 0,025 | 0,025 | - |
| E355 | 1,0580 | 0,22 | 0,55 | 1,60 | 0,025 | 0,025 | - |
Product Highlights
Kohlenstoffstahl-Rauchrohr-Wärmetauscher-nahtloses Rohr DIN2391 ST37.4 NBK 12*1MM Kohlenstoffstahl-Rauchrohr-Wärmetauscher-nahtloses Rohr DIN2391 ST37.4 NBK 12*1MM Kaltbezogene nahtlose Rohre der Präzisions-DIN2391 und Rohre, GR St35 St45 St52 St37.4, kalter fertiger Gebrauch des nahtlosen Rohres f...
Schweißende kundengebundene Hochfrequenzkohle feuerte Dampfkessel-Teile stapeln Ekonomiser-Spule ab
High Frequency Welding Customized Coal Fired Steam Boiler Parts Stack Economizer Coil Boiler economizer Boiler Economizer is the energy improving device that helps to reduce the cost of operation by saving the fuel. The economizer in Boiler tends to make the system more energy efficient. In boilers, economizers are generally designed to exchange heat with the fluid, generally water. The exhaust from the boilers is generally in the temperature range of 200°C – 250°C, so there
Schweißendes Kessel-gewundenes Flossen-Hochfrequenzrohr für Ekonomiser-Wärmeübertragung
High Frequency Welding Boiler Spiral Fin Tube For Economizer Heat Transfer Boiler economizer Boiler Economizer is the energy improving device that helps to reduce the cost of operation by saving the fuel. The economizer in Boiler tends to make the system more energy efficient. In boilers, economizers are generally designed to exchange heat with the fluid, generally water. The exhaust from the boilers is generally in the temperature range of 200°C – 250°C, so there are a huge
Art Kessel-Teil-Rohr des Wärmetauscher-H für Gebrauchskraftwerk-Anlage
High Efficient Heat Exchang H Type High Temperature Resistance Boiler Parts For Utility/Power Station Plant Product Introduce H-fin Tubes have two steel discs,with fluorescent tubes symmetrically welded together to form fins(fins of butterfly piece)creating a shape that looks somewhat like the letter"H",creating an efficient energy saving, extension heating surface.H-fin Tubes also have a high rate of fusion welds and weld tensile strength.H-fin Tube is assembled with the H
Erweiterungs-Heizfläche-Kessel-Flossen-Rohr für Wirtschaftsmacht-Kraftwerk-Kessel
Energy Saving Extension Heating Surface Boiler Fin Tube For Industrial Power Plant Boiler Product Description H-fin Tubes have two steel discs,with fluorescent tubes symmetrically welded together to form fins(fins of butterfly piece)creating a shape that looks somewhat like the letter"H",creating an efficient energy saving, extension heating surface. H-fin Tubes also have a high rate of fusion welds and weld tensile strength.H-fin Tube is assembled with the H economizer,
